| Projection Technology | DLP |
| Display Chip | 0.67"DMD |
| Center Brightness | 15,000 lumens |
| ISO Brightness | 14,200 ISO lumens |
| Resolution | 1,920 X 1,200 (16:10) 4 K input |
| Contrast Ratio | 50,000:1(Dynamic),3,000,000:1(Ultimate Black) |
| Light Source | MCL laser light source |
| Light Source Life | 20,000 hour |
| Lens | 0.3/0.35-0.39/0.361/0.47-0.49/0.48/0.5/0.6/0.63/0.65-0.75/0.7/0.75-0.95/0.8/0.85-1.35/0.85-1.45/ 0.9/0.95-1.22/1.2-2.0/1.22-1.52/1.52-2.92/2.90-5.50/5.0-8.0/5.5-9.3 |
| Screen Size | 30"~300" |
| Lens Shift | Vertical: ±50% /Horizontal: ±15% (half screen);Vertical: ±100% /Horizontal: ±30% (full screen); For half-screen displacement: Vertical: ±50% / Horizontal: ±15%For full-screen: Vertical: ±100% / Horizontal: ±30% |
| Image Correction | HorizontalVertical,correction point Horizontal and vertical keystone correction, correction point stretching |
| 360° Projection | Support support |
| 3D | Support3 D3 D SYNCinterface; Support 3 D |
| Edge Blending | Support support; Top edge/Bottom edge/Left edge/Right edge : 0% ~ 50% Upper edge/Lower edge/Left edge/Right edge: 0% ~ 50% |
| HDBaseT | 10.2 Gbps HDMI 1.4(HDCP)100 MbpsEthernet It can achieve |
| Interfaces | Support4 Kinput; HDMI2.0 x2, HDBaseT x 1, DVI -D x1, 3 G-SDI*1 3 D-Sync in x1; HDMI Out X 1, 3 D SYNC OUT*1; LAN(RJ45)*1, WIRED IR*1 , RS-232 X 1, 12 V OUT*1, 5 V/2a USB-A*1 |
| Control Protocol | PJLink / AMX /Extron/TCP/RS232 |
| Noise | 40dB(Typical) 37dB(Eco) |
| Power | 100-220 V AC±10%,50/60 Hz; 895 W+/-15%(max) |
| Temperature | 0°C ~ 40°C; -10°C ~ 60°C |
| Humidity | 5%~90% RH; 10%~85% RH |
| Warranty | 3 years |
| Number Of Correction Points | 2x2 / 3x3 / 5x5 / 9x9 / 17x17 |
| Dimensions | 484*532*200 mm |
| Weight | 21KG |
