| Projection Technology | DLP |
| Display Chip | 0.96"DMD |
| Laser Display Technology | + Blue laser+fluorescent powder technology |
| Center Brightness | 21,000lumens(lumen) |
| ISO Brightness | 20,500 ISOlumens |
| Resolution | 1,920*1,200(16:10) |
| Contrast Ratio | 5,000,000:1 |
| Light Source Life | 20,000 hour |
| Lens | 0.56/0.62/0.8/0.65-0.75/0.84-1.02/0.85-1.45/1.02-1.36/1.2-1.5/1.5-2.0/ 2.0-4.0/2.1-3.7/3.6-6.3/4.0-7.2/7.2-10.8; motorized lens Electric lens |
| Throw Ratio | ≥90% |
| Aspect Ratio | 16:10(16:9,4:3) |
| Image Correction | Horizontal(level)±25%;Vertical(vertical)±60%; SupportHorizontalVerticalkeystone correction,,, Supports horizontal and vertical trapezoidal correction, pillow shape correction, corner adjustment, and geometric correction; 2*2~17*17grid Lattice point |
| 3D | SupportHDMI 1.4 B3 D,Support3 D Supports HDMI 1.4b forced format active 3 D, supports multiple active 3 D synchronization |
| Interfaces | RS232 in x1, RS232 out x1, RJ45 x1, Wire Remote in x1, Wire Remote out x1, USB Ax1; Displayx1,HDMI 2.0 x2, DVI-D x1, VGA x1, HDBaseT x1, 3 D sync in x1, 3 G-SDI in x1; HDMI out x1, 3 D sync out x1, 12 V x1, 3 G-SDI out x1 |
| Power | 110-240 V(±10%); (Full load power consumption)1350 W@220 VAC |
| Dimensions | 682*650*301 (mm) |
| Weight | 40(db); 50(kg) |
| Warranty | 3 years |
| Appointment Scheduling | Support support |
| Av Mute Timer | Support support |
| Black Scale Compensation | Support support |
| Brightness Adjustment | Support support(0~100) |
| Color Optimization | Support support |
| Dynamic Black | Support support HDR: Support support |
| Edge Fusion | Support support |
| Extremely Black | Support support |
| Gamma Adjustment | Support support |
| Hsg Regulation | Support support PIP/PBP: Support support |
| Installation Method | 2*360° |
| Osd Multilingual | Supports 16 languages |
| Signal Backup | Support support |
