| Projection Technology | 3 LCD |
| Display Chip | 3*0.64" |
| Brightness | 5,300 ISO lumen |
| Center Brightness | 5,500 lumen |
| Resolution | 1,920*1,200(16:10) |
| Contrast Ratio | 5,000,000:1; 11*17grid (Quadrangle stretching, hexagonal stretching, pillow correction, barrel correction, 11 * 17 grid point correction) |
| Light Source | MCL laser light source(laser source) |
| Light Source Life | 20,000 hour |
| Lens | F 1.7, F 2.94mm; /( Corner/center separation focusing technology); ( hand movement) |
| Throw Ratio | 0.235 Offset: 117% |
| Screen Size | 80"~120" |
| Uniformity | ≥80% |
| Image Correction | 2*360°; V: ±5° H:±5° |
| Interfaces | VGA*1,HDMI 1.4 B(IN) *2,USB-A*1,USB-B*1(Display),RJ45*1(Display), Audio in(mini jack,3.5mm)*1; VGA*1,Audio out(mini-jack,3.5mm)*1; RS232*1,RJ45*1 (Control),USB-B*1 (For upgrade) |
| Control Protocol | RoomView (Crestron), AMX Discovery, PJ Link |
| Speaker | 16 W*1 |
| Noise | 37decibel |
| Power | 100~240 V@ 50/60 Hz; (Normal) (Max) 360 W,(ECO1) (Max) 280 W, (ECO2) (Max) 230 W |
| Dimensions | 520*435*168(mm) |
| Weight | 11(kg) |
| Warranty | 3 years |
| Color Range | 105% REC.709 |
| Compatibility | VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4 K@30 Hz |
| Custom Features | Support(support) |
| Lifting And Flipping | Support(support) |
| Red Light Proportion | 15% |
| Usb Video Transmission | Support(support) |
