| Projection Technology | DLP |
| Display Chip | 0.67"DMD |
| Brightness | 7,000 ISOlumens(lumen) |
| Center Brightness | 7,100lumens(lumen) |
| Resolution | 1,920*1,200(16:10) |
| Contrast Ratio | 300,000:1 Dynamic(trends) , 5,000,000:1 Ultimate Black(Ultimate Black); HorizontalVerticalkeystone correction,correction point (Horizontal and vertical trapezoidal correction, correction point stretching) |
| Light Source | MCL laser light source(laser source) |
| Light Source Life | 20,000 hour |
| Lens | 1.22~1.53, 0.35, 0.48, 0.53-0.65, 0.6, 0.7, 0.75-1.12, 0.8, 0.75~0.95, 0.95, 0.95~1.22/1.5-3.0, 1.52~2.92, 2.90~5.50 |
| Screen Size | 30"~300" |
| Lens Shift | (electric)V: ±50%,H: ±15% |
| Image Correction | 2*360° |
| Interfaces | VGA In X 1, Audio In Jack X 1, HDMI1.4 x1, HDMI2.0 x1, HDBaseT x 1, 3 D SYNC IN*1; HDMI Out X 1, Audio Out Jack X 1, 3 D SYNC OUT*1; LAN*1,WIRED IR*1 ,RS-232 X 1, 12 V OUT*1,5 V/1,5a USB*1 |
| Control Protocol | PJLink / AMX /Extron/TCP/RS232 |
| Speaker | 10 W*2 |
| Noise | 34decibel |
| Power | AC 90-264 V~50/60 Hz; 330 W |
| Dimensions | 480*139*376(mm) |
| Weight | 12(kg) HDBaseT: 10.2 Gbps HDMI 1.4(HDCP)100 MbpsEthernet (Can achieve 10.2 Gbps HDMI 1.4 transmission (including HDCP) and 100 Mbps Ethernet) HDMI 2.0: Support4 Kinput (Supports 4 K input) 3 D: Support3 D3 D SYNCinterface (Supports active 3 D with 3 D SYNC synchronization interface) |
| Warranty | 3 years |
