| Projection Technology | DLP |
| Display Chip | 0.67"DMD |
| Brightness | 8,000 ISOlumens(lumen) |
| Center Brightness | 8,360lumens(lumen) |
| Resolution | 1,920*1,200(16:10) |
| Contrast Ratio | 300,000:1 Dynamic(trends) , 5,000,000:1 Ultimate Black(Ultimate Black); HorizontalVerticalkeystone correction,correction point (Horizontal and vertical trapezoidal correction, correction point stretching) |
| Light Source | MCL laser light source(laser source) |
| Light Source Life | 20,000 hour |
| Lens | 1.22~1.53(standard lens), 0.35, 0.48, 0.53-0.65, 0.6, 0.7, 0.75-1.12, 0.8, 0.75~0.95, 0.95, 0.95~1.22/1.5-3.0, 1.52~2.92, 2.90~5.50 |
| Screen Size | 30"~300" |
| Lens Shift | (electric)V: ±55%,H:±25% |
| Image Correction | 2*360° |
| Interfaces | HDMI1.4*1,HDMI2.0*1, 3 DSYNCIN*1; AudioOutJackX*1,3 DSYNCOUT*1; LAN*1,RS-232 X*1,USB*1,USB-A*1 BIC (systems) |
| Control Protocol | PJLink / AMX /Extron/TCP/RS232 |
| Speaker | 10 W*2 |
| Noise | 32decibel |
| Power | AC100-240,50/60 Hz; 405 W@220 VAC |
| Dimensions | 480*139*376(mm) |
| Weight | 12(kg) HDBaseT: 10.2 Gbps HDMI 1.4(HDCP)100 MbpsEthernet (Can achieve 10.2 Gbps HDMI 1.4 transmission (including HDCP) and 100 Mbps Ethernet) HDMI 2.0: Support4 Kinput (Supports 4 K input) 3 D: Support3 D3 D SYNCinterface (Supports active 3 D with 3 D SYNC synchronization interface) |
| Warranty | 3 years |
| Bullet Screen | Support,Support |
| Chromatic Aberration Adjustment | Support |
| Controlling Projection | Support |
| Customized Boot Screen | Support |
| Device Lock | Support |
| Edge Fusion | Support0%-100%fusion zone |
| Mask Function | Support |
| Picture Correction | Horizontal/Vertical//,Support2*2~40*40grid |
| Picture Playback | Support |
| Playback Control | Supportapp |
| Product Monitoring | Support |
| Ring Screen Fusion | Support360°fusion |
| Screen Softening | Support |
| Source Mall | Supportapp,fusion screen |
| Telecontrol | Supportapp |
| Window Function | Support, Support,Support |
